Planning project

Architectural site plan sheet AS101 for the hospital campus, showing existing and under-construction buildings, parking, fuel tanks and a keynote legend.

May 2, 2025 · 1 page · 890 KB · PDS-Other Small Docs

Northwest parking garage elevation sheet with general EIFS notes, an EIFS thickness legend, and a note to replace existing horizontal louvers with directional vertical louvers.

May 2, 2025 · 1 page · 1.2 MB · PDS-Other Small Docs

Architectural floor plan sheets for the parking garage, with general notes and keynotes for replacing existing louvers and adding fire sprinklers and an expansion joint cover.

May 2, 2025 · 6 pages · 3.1 MB · PDS-Other Small Docs

May 2, 2025 · 1 page · 329 KB · PDS-Other Small Docs

Planner notes on a proposed façade change near the parking garage, adding fire-separation EIFS walls and replacing exhaust louvers with vertical louvers painted in-kind.

May 2, 2025 · 1 page · 443 KB · PDS-Concept Review Summary Report

Design review letter from the project architect explaining added fire-separation walls at the parking garage and replacement exhaust louvers for the medical office plaza.

May 2, 2025 · 1 page · 142 KB · PDS-Other Small Docs

Application form for a medical outpatient care facility and medical offices in an MX-H zone, filed by Architectural Nexus for St. Luke's Regional Medical Center.

May 2, 2025 · 2 pages · 154 KB · PDS-Application
